2D Logger Stick 2 CAN – V2

Login to view prices

2D Datareconding Configurable CAN logger 2 CAN


2D-Data Recording Configurable CAN Memory logger, open and fully configurable version with 2 CAN bus Line. It’s professional level logger for data recording in complex system, with a Can bus connected to the Ecus and powertrain line, and other one to external device like DashBoard, expander, TPMS and more.. Hardware 2th version. Bridging functions of frame and channels between the canbus lines, also with different data rate.

  • A WinAnalyzer entry level software license included
  • 2 CAN lines for up to 128 CAN
  • 32MB Internal Memory
  • Internal Mathematical Channels
  • Stores CAN Bus data directly to USB Stick or to Internal Memory
  • Can Bus Sampling Rate up to 200 HZ ( up to 800 Optional )
  • Supports Hot swap!
  • Developed for ultimate Data access speed
  • GPS direct input
  • 2 analog input channels 16 BIT
  • IP67
  • Temperature Operating Range -20….+60°C
  • Weight 90gr
  • Dimension 70x40x13mm
  • The versions dedicated to the applications like Moto2, have some firmware/software restrictions like a locked configuration and shouldn’t be used in differents championship or applications.

Additional information

Weight 0,50 kg

JuniorGP Moto2, WSS300, Standard, Wss


Here the datasheet :
